Installing Remote Desktop Services (RDS) on Windows Server 2019 appears to take many steps, but in reality is quite easy. In this article, we dive into how to install these services in a domain environment that requires two servers.

There are only two necessary steps before we embark on installing RDS. Those are:

  • All servers are domain joined
  • There are at least two available servers

The reason that we need two servers is that the RD Licensing role will go on the second server rather than all on one, as this is considered a Microsoft best practice. In this tutorial, we use the Domain Controller as the RD License server which would not be considered best practice. The reason for doing this in this tutorial is to keep the installation simple.

Installation of Remote Desktop Services base roles

  • RD Connection Broker
  • RD Web Access
  • RD Session Host

  1. Within Server Manager on the primary RDS server that we are installing, open the Add Roles and Features Wizardand select Remote Desktop Services installation.
Windows Server 2019 Hyper-V New Features

2. For this tutorial we are going to choose Quick Start, but if you need further control over the installation process, you can use the Standard Deployment to modify more options during installation.

Windows Server 2019 Hyper-V New Features

3. Next, we will choose Session-based desktop deployment, as this is a common RemoteApp and desktop session model that is commonly used in more traditional RDS deployments.

Windows Server 2019 Hyper-V New Features

4. In the Server Selection, choose the server where we are installing RDS.

Windows Server 2019 Hyper-V New Features

5. Choose Restart the destination server automatically if required and click on Deploy to start the installation.

Windows Server 2019 Hyper-V New Features

6. Verify that all roles have succeeded in installation before moving on to the next steps.

Windows Server 2019 Hyper-V New Features

Add secondary server

For this tutorial, we are going to use the Domain Server as our RD Licensing server, but to easily install that role, we can add an additional server to the Server Manager.

  1. Add the secondary server by right-clicking on the All Servers, choosing Add Servers, and then picking the server from Active Directory.

2. Navigate to Remote Desktop Services and click on the green plus for RD Licensing.

Windows Server 2019 Hyper-V New Features

3. The Add RD Licensing Servers screen will appear and that will let you add the secondary server as a target for the RD Licensing role.

Windows Server 2019 Hyper-V New Features

4. Click on Add to install the role on the secondary server.

Windows Server 2019 Hyper-V New Features

5. Verify that the installation is complete by seeing the green plus replaced by the proper icon in RD Licensing.

Windows Server 2019 Hyper-V New Features

Add RD Gateway Role

Finally, we need to add the RD Gateway Role to our primary RDS server.

  1. Under the Remote Desktop Services screen, click on the green plus over RD Gateway.
  2. Select the primary RDS server to use for the installation of this role.
Windows Server 2019 Hyper-V New Features

3. Name the self-signed SSL certificate with a Fully-Qualified Domain Name.

Windows Server 2019 Hyper-V New Features

4. Click on Next and then Add to install the role to our primary RDS server.

Windows Server 2019 Hyper-V New Features

Configure deployment properties

Now that all the roles have been installed, we can configure the actual deployment properties.

  1. Navigate to the Remote Desktop Services screen and under the Tasks dropdown, click on Edit Deployment Properties.
Windows Server 2019 Hyper-V New Features

2. Leave the default settings on the RD Gateway screen and click on the RD Licensing menu item.

Windows Server 2019 Hyper-V New Features
Windows Server 2019 Hyper-V New Features

4. Note the URL of the RD Web Access screen as this will be used later to access the applications deployed.

Windows Server 2019 Hyper-V New Features

5. For the purposes of testing, you can leave the certificates Not Configured, and finally click on OK to save the deployment configuration.

Windows Server 2019 Hyper-V New Features

If you do want to configure a certificate, you will have to do this for each and every role service individually

By default, a QuickSessionCollection was created upon installation that contains Calculator, WordPad, and Paint as RemoteApps. This can be used to test the RDP deployment.

  1. Navigate to the IIS URL originally located in RD Web Access, or you can use https://localhost/rdweb/ if you are located on the RDP server itself, to test IIS.
Windows Server 2019 Hyper-V New Features

2. Log into the IIS RDS session using domain credentials.

Windows Server 2019 Hyper-V New Features

3. Finally, launch a remote connection, either one you have defined or a default RemoteApp.

Windows Server 2019 Hyper-V New Features
